Garrett Turbo Charger Supercore GTW3884 62/64/67mm (Less Turbine Housing)
- Bearing System: Journal Bearing
- Cooling System: Oil Cooled Only
- Horsepower: 450 - 800
- Ported Shroud Design for Surge Resistance
- Available in both Journal Bearing and Ball Bearing options
- Forged Fully Machined Billet Compressor Wheel
- Lightweight Aluminium Backplate
- Inconel Super-Alloy Turbine Wheel
| Super Core Reference Data |
Compressor |
Turbine |
| Super Core PN |
CHRA PN |
Inducer |
Exducer |
Trim |
A/R |
Inducer |
Exducer |
Trim |
| 841297-5003S |
715582-0008 |
62mm |
84mm |
54 |
0.70 |
74mm |
65mm |
76 |
| 841297-5004S |
715582-0009 |
64mm |
84mm |
58 |
0.70 |
74mm |
65mm |
76 |
| 841297-5005S |
715582-0010 |
67mm |
84mm |
64 |
0.70 |
74mm |
65mm |
76 |
| 841691-5003S |
757197-0012 |
62mm |
84mm |
54 |
0.70 |
74mm |
65mm |
76 |
| 841691-5004S |
757197-0013 |
64mm |
84mm |
58 |
0.70 |
74mm |
65mm |
76 |
| 841691-5005S |
757197-0014 |
67mm |
84mm |
64 |
0.70 |
74mm |
65mm |
76 |
| Notes: |
Turbine Kit PN |
A/R |
Inlet |
Outlet |
Wastegate |
Divided |
Trim |
| Super Core and Turbine Kit Sold Separately |
844669-0005 |
0.70 |
T4 |
V-Band |
Free Float |
Y |
76 |
| 844669-0013 |
0.84 |
T4 |
V-Band |
Free Float |
Y |
76 |
| 844669-0011 |
1.00 |
T4 |
V-Band |
Free Float |
Y |
76 |
| 407263-0035 |
1.32 |
T4 |
V-Band |
Free Float |
Y |
76 |
