- Bearing Type: Ball Bearing
- Cooling System: Oil & Water Cooled
-
Turbine Housing: Externally Wastegated 0.72a/r or 0.57a/r
- Base Flange: V-Band Single Entry
- Exhaust Outlet Flange: V-Band
- Horsepower: 200 - 475hp
- Displacement: 1.4L - 2.5L
Features
- GEN 2 Aerodynamics feature increased horsepower range
- New fully-machined Speed Sensor port
- Improved ported shroud design for surge resistance
- Sold as complete assembly kits (Supercore + Turbine Kit)
- Interchangeable with GT and GTX GEN I Models
Product Notes:
- Directly interchangeable with the GT2860RS, GT2871RS, GTX2860R GEN I, GTX2863R GEN I, and GTX2867R GEN I
- Supplied complete with turbine housing inlet and outlet v-band clamps, and Turbine Housing lock plates.
- Inlet & Outlet Flanges sold separately.
| Supercore Reference Data | Compressor | Turbine | ||||||
|---|---|---|---|---|---|---|---|---|
| Supercore P/N | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | |
| 849894-5001S | 46mm | 60mm | 58 | 0.60 | 54mm | 47mm | 76 | |
| Turbocharger P/N | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | A/R |
| 856800-5002S | 46mm | 60mm | 58 | 0.60 | 54mm | 47mm | 76 | 0.72 & 0.57a/r |
